Catalog
Order No.
|
Capacity
@load
center
(Kg@mm)
|
Mounting
Class
|
Opening
Range
(mm)
|
Available
Forklift
|
Arm Height (mm)
|
Arm
Length (mm)
|
Frame width
(mm)
|
Overall height
(mm)
|
Weight
(Kg)
|
Effective
Thickness
(mm)
|
|
RJ19RT-A1
|
800@500
|
Ⅱ
|
445-1670
|
1-2.5t
|
420
|
996
|
1040
|
796
|
580
|
198
|
|
RJ25RT-A1
|
2500@500
|
Ⅱ
|
600-1880
|
2-2.5t
|
460
|
1200
|
1010
|
769
|
750
|
259
|
|
RJ30RT-B1
|
2700@500
|
Ⅲ
|
560-1850
|
3-4.5t
|
460
|
1200
|
1010
|
769
|
750
|
259
|
Note:
1, the actual truck / carrying capacity is a comprehensive factory obtained from the forklift.
2, this is a matching increase in group 2 required additional forklifts require asphalt.
Pressure for flow meter
|
Model
|
Pressure value（Bar）
|
Flow value（L/min）
|
|
Least
|
Max
|
Lateral movement
|
Clamping action
|
|
Least
|
Recommend
|
Maximum
|
Least
|
Recommend
|
Maximum
|
|
RJ**RT
|
35
|
180
|
19
|
26
|
38
|
19
|
26
|
38
|
Rotating torque requirements
|
Model
|
Speed
|
Torque
|
|
RJ19RT
|
3.5r/min@38L/min
|
4200N.m@160Bar
|
|
RJ25RT
|
3.5r/min@38L/min
|
9000N.m@160Bar
|
|
RJ30RT
|
3.5r/min@38L/min
|
9000N.m@160Bar
|
