Rotators 1ton -7ton
Model Rotators XZ***
Note: 1, the actual truck / carrying capacity is a comprehensive factory obtained from the forklift. 2, can be added according to user needs picking fork. Please note that the carrying capacity of their own fork. 3, required additional forklifts need to increase a group of asphalt. 4 rotator by picking the right fork to increase welding hook, rotor machine factory were included in the hook. Pressure for flow meter
Rotating torque requirements
An important component of a product configuration Hydraulic system: hydraulic motor and foreign companies jointly developed by a new generation of products; rotating hinge and seal oil are imported products. Rotating two-way hydraulic oil circuit, self-locking, ensuring safety at work. Structural parts: the slewing bearing slewing bearings with large modulus, the load capacity; worm and worm involute tooth profile, can improve efficiency, reduce heat loss, but also to achieve self-locking feature. Mechanical performance: the case can be achieved with a 360 ° two-way rotation, a group of asphalt can be added to meet the requirements; standard fork can be used directly without modification. Application: widely used in food, automation, chemical, materials recycling, smelting foundry industries, as well as any need to rotate the hopper or box tipping and mixing occasions, the goods can quickly flip or conversion, and then immediately coherent the fork back to its original location.
